232.20.1000.503 Type 21/1200.2

Design Features of 232.20.1000.503 Ball 21/1200.2 Bearing

232.20.1000.503 Ball 21/1200.2 features an inner and outer ring with four contact points between the steel balls and the rings, allowing for the support of radial, axial, and tilting loads. 232.20.1000.503 Ball 21/1200.2 inside diameter of inner ring is 38.803″. Its outside diameter of outer ring is 47.165″. Its design provides high load capacity, durability, and smooth rotation, making it ideal for applications requiring precise, high-torque performance.

What Benefits Can 232.20.1000.503 Ball 21/1200.2 Bearing Provide?

• High Load Capacity: Supports radial, axial, and tilting loads simultaneously, making it ideal for heavy-duty applications.
• Compact Design: Offers high performance in a compact form, saving space in mechanical systems.
• Smooth Rotation: Provides smooth and precise movement with minimal friction, ensuring reliable operation.
• Durability: Designed to withstand harsh conditions and long-term use, offering extended service life.
• Versatility: Suitable for a wide range of applications, including cranes, excavators, and solar tracking systems.

What Can 232.20.1000.503 Ball 21/1200.2 Bearing Be Used for?

• Cranes and Excavators: Used in heavy machinery for rotating and lifting functions.
• Solar Tracking Systems: Enables smooth and precise tracking of solar panels to optimize energy capture.
• Wind Turbines: Facilitates the rotation of the turbine for optimal positioning and energy generation.
• Radar and Antenna Systems: Provides stable rotation for radar dishes and communication antennas.
• Offshore and Marine Equipment: Used in rotating equipment like winches and turntables in marine and offshore platforms.
