Part Number | 719/4C |
System of Measurement | Metric |
Contact Angle | 15° |
Seal Type | Sealed,Open |
Matched Arrangement | Universal matching |
Preload | Available |
For Load Direction | Angular Contact |
Bore Dia | 4 mm |
Outer Dia | 11 mm |
Width | 4 mm |
Ball Material | Steel,Ceramic |
Cage Material | Nylon,Phenolic |
Dynamic Radial Load | 181.86 lbf |
Static Radial Load | 65.19 lbf |
Grease Limited speed (r/min) | 93000 |
Oil Limited speed (r/min) | 98000 |
Lubrication | Lubricated |
ABEC Rating | P5(ABEC-5),P4(ABEC-10) |
Weight | 0.0018 kg |
