| Part Number | ADB22V(L) |
| System of Measurement | Inch |
| Bore Dia | 1.375″ |
| Bore Dia Tolerance | -0.0005″ to 0″ |
| Outer Dia | 2.5625″ |
| Outer Dia Tolerance | -0.0005″ to 0″ |
| Ball Width | 1.375″ |
| Ball Width Tolerance | -0.002″ to 0″ |
| Race Width | 1.1″ |
| Race Width Tolerance | -0.005″ to +0.005″ |
| Shoulder Dia | 1.654″ |
| Ball Dia | 2.156″ |
| Pitch Dia | 2.44″ |
| Mis Alignment | 8° |
| Groove Depth | 0.055″ |
| Dynamic Radial Load | 64680 lbs |
| Static Radial Load | 161700 lbs |
| Weight | 1.28 lbs |
