S16005 Stainless Steel Bearings

Design Features of S16005 Stainless Steel Bearings Bearing

S16005 Stainless Steel Bearings Bearing represents a precise melding of advanced metallurgy and engineering. Crafted from AISI440C stainless steel, it is uniquely tailored for applications that require a combination of corrosion resistance and hardness. S16005 Stainless Steel Bearings bore dia is 25 mm. Its out dia is 47 mm. Its width is 8 mm. S16005 Stainless Steel Bearings Bearing offers a blend of durability, precision, and compatibility tailored for specific operational needs.



What Benefits Can S16005 Stainless Steel Bearings Bearing Provide?

  • Corrosion Resistance: Thanks to AISI440C stainless steel,  this bearing is resilient against moisture and certain chemicals.
  • Durability: AISI440C’s hardness ensures long-lasting performance under heavy loads.
  • Versatility: It operates effectively across diverse temperatures and conditions.
  • Precision: Reduced friction for smoother operations and energy savings.



What Can S16005 Stainless Steel Bearings Bearing Be Used for?

S16005 Stainless Steel Bearings Bearing is commonly used in applications such as:

  • Marine Applications: Its corrosion resistance makes it ideal for environments with moisture and salinity.
  • High-Load Systems: The hardness of AISI440C ensures this bearing can handle heavy loads efficiently.
  • Precision Equipment: Instruments requiring reduced friction and high accuracy benefit from this bearing.
  • Extreme Conditions: Effective across varying temperatures and conditions, making it suitable for both hot and cold environments.

Part Number S16005 Stainless Steel Bearings
System of Measurement Metric
Ring Material



Cage Material

Balls Material

Bearing Type Ball
For Load Direction Radial
Construction Single Row
Seal Type Open
Bore Dia 25 mm
Bore Dia Tolerance -0.01mm to 0
Outer Dia 47 mm
Outer Dia Tolerance -0.011mm to 0
Width 8 mm
Width Tolerance -0.120mm to 0
Dynamic Radial Load 6300 N
Static Radial Load 4140 N
Max Speed (X1000 rpm) 9.9
Lubrication Required
Shaft Mount Type Press Fit
Temperature Range -30° to 110 °C
ABEC Rating ABEC-1
Radial Clearance Trade No C0
Radial Clearance 0.006mm to 0.020mm
RoHS Compliant
Weight 60 g
