Part Number | S1601 2rs Stainless Steel Bearings |
System of Measurement | Inch |
Ring Material
|
|
Cage Material |
|
Balls Material |
|
Bearing Type | Ball |
For Load Direction | Radial |
Construction | Single Row |
Seal Type | Sealed |
Bore Dia | 0.1875″ |
Bore Dia Tolerance | -0.0003″ to 0″ |
Outer Dia | 0.6875″ |
Outer Dia Tolerance | -0.0003″ to 0″ |
Width | 0.3125″ |
Width Tolerance | -0.005″ to 0″ |
Dynamic Radial Load | 540 lbf |
Static Radial Load | 198 lbf |
Max Speed (X1000 rpm) | 4.5 |
Lubrication | Required |
Shaft Mount Type | Press Fit |
Temperature Range | -86 to 230 °F |
ABEC Rating | ABEC-1 |
Radial Clearance Trade No | C0 |
Radial Clearance | 0.00008″ to 0.00051″ |
RoHS | Compliant |
Weight | 4 g |

S1601 2rs Stainless Steel Bearings
Design Features of S1601 2rs Stainless Steel Bearings Bearing
S1601 2rs Stainless Steel Bearings Bearing represents a precise melding of advanced metallurgy and engineering. Crafted from AISI440C stainless steel, it is uniquely tailored for applications that require a combination of corrosion resistance and hardness. S1601 2rs Stainless Steel Bearings bore dia is 0.1875″. Its out dia is 0.6875″. Its width is 0.3125″. S1601 2rs Stainless Steel Bearings Bearing offers a blend of durability, precision, and compatibility tailored for specific operational needs.
What Benefits Can S1601 2rs Stainless Steel Bearings Bearing Provide?
- Corrosion Resistance: Thanks to AISI440C stainless steel, this bearing is resilient against moisture and certain chemicals.
- Durability: AISI440C’s hardness ensures long-lasting performance under heavy loads.
- Versatility: It operates effectively across diverse temperatures and conditions.
- Precision: Reduced friction for smoother operations and energy savings.
What Can S1601 2rs Stainless Steel Bearings Bearing Be Used for?
S1601 2rs Stainless Steel Bearings Bearing is commonly used in applications such as:
- Marine Applications: Its corrosion resistance makes it ideal for environments with moisture and salinity.
- High-Load Systems: The hardness of AISI440C ensures this bearing can handle heavy loads efficiently.
- Precision Equipment: Instruments requiring reduced friction and high accuracy benefit from this bearing.
- Extreme Conditions: Effective across varying temperatures and conditions, making it suitable for both hot and cold environments.
