KP-B

Overview of KP-B Series Bearings

The KP-B Series offers a range of extra light duty, single-row ball bearings designed primarily for aerospace and high-precision control applications. These bearings are built to meet stringent performance and durability requirements while minimizing overall system weight. Their design is ideal for applications involving limited space, moderate loading, and rotational precision.

Key Technical Features

• Material: Bearing rings and balls are crafted from high-quality AISI 52100 chrome steel, delivering excellent wear resistance and fatigue life.
• Seal Design: Equipped with removable PTFE (Polytetrafluoroethylene) seals for effective contaminant exclusion and easy maintenance.
• Temperature Range: Operating temperatures span from -65 °F to +250 °F (-54 °C to +121 °C), suitable for both high-altitude and ground-based control systems.
• Lubrication: Pre-lubricated with MIL-PRF-81322 synthetic grease, ensuring consistent performance under vibration and thermal stress. Grease fill is at a minimum of 80% unless otherwise specified.
• Plating: External surfaces (excluding the bore) are cadmium plated per AMS-QQ-P-416 to enhance corrosion resistance and durability. Dimensional tolerances account for post-plating finish.

Applications

KP-B Series bearings are commonly used in:

• Aerospace control systems (e.g., ailerons, rudders, flaps)
• Actuation mechanisms in avionics and unmanned systems
• Lightweight industrial and defense assemblies requiring compact bearing solutions

Customization Options

To meet specific design or regulatory requirements, the KP-B Series bearings can be customized in the following aspects:

• Alternative materials (e.g., stainless steel, hybrid ceramic)
• Custom dimensions and tolerances
• Special internal clearances and preloads
• Different lubricants for extreme environments or cleanroom use
• Environmentally compliant plating options (e.g., RoHS-compliant finishes)

Dimensional Information

All dimensions for the KP-B Series bearings are provided in inches unless otherwise noted. CAD drawings and datasheets are available to assist in integration and selection.

For detailed technical support or to request a customized quote, please contact our engineering team.
