KP10A
| Part Number | KP10A |
| Standard Reference | MS27641-10 |
| System of Measurement | Inch |
| Bore Dia | 0.3125″ |
| Bore Dia Tolerance | -0.0005″ to 0″ |
| Outer Dia | 1.375″ |
| Outer Dia Tolerance | -0.0005″ to 0″ |
| Ring Width Outer Height | 0.344″ |
| Ring Width Outer Height Tolerance | -0.005″ to 0″ |
| Ring Width Inner Width | 0.406″ |
| Ring Width Inner Width Tolerance | -0.005″ to 0″ |
| Ball Complement No | 14 |
| Ball Complement Dia | 7/32″ |
| Ring Shoulder Outer | 1.242″ |
| Ring Shoulder Inner | 0.768″ |
| Ring Chamfer Outer | 0.032″ |
| Ring Chamfer Outer Tolerance | 0″ to 0.015″ |
| Ring Chamfer Inner | 0.015″ |
| Ring Chamfer Inner Tolerance | 0″ to 0.015″ |
| Radial Internal Clearance | 0.0004″ to 0.001″ |
| Static Radial Load | 6700 lbs |
| Static Thrust Load | 3000 lbs |
| Dynamic Radial Ring Inner Load | 4980 lbs |
| Dynamic Radial Ring Outer Load | 4360 lbs |
| Max Starting Torque | 3 oz-in |
| Weight | 0.04 lbs |
$76.71
