MKP37BS
| Part Number | MKP37BS |
| System of Measurement | Inch |
| Bore Dia | 2.3125″ |
| Bore Dia Tolerance | -0.0005″ to 0″ |
| Outer Dia | 3.25″ |
| Outer Dia Tolerance | -0.0010″ to 0″ |
| Ring Width Outer Height | 0.375″ |
| Ring Width Outer Height Tolerance | -0.005″ to 0″ |
| Ring Width Inner Width | 0.437″ |
| Ring Width Inner Width Tolerance | -0.0025″ to 0″ |
| Ball Complement No | 45 |
| Ball Complement Dia | 3/16″ |
| Ring Shoulder Outer | 2.516″ |
| Ring Shoulder Inner | 3.051″ |
| Ring Chamfer Outer | 0.024″ |
| Ring Chamfer Outer Tolerance | 0″ to 0.015″ |
| Ring Chamfer Inner | 0.024″ |
| Ring Chamfer Inner Tolerance | 0″ to 0.015″ |
| Radial Internal Clearance | 0.0001″ to 0.0005″ |
| Static Radial Load | 15800 lbs |
| Static Thrust Load | 3200 lbs |
| Dynamic Radial Ring Inner Load | 4880 lbs |
| Dynamic Radial Ring Outer Load | 4690 lbs |
| Max Starting Torque | 20 oz-in |
| Weight | 0.33 lbs |
$537.45
